Scaffold Azure DevOps Repositories Using Cookiecutter

Overview​

This guide will help you implement a self-service action in Port that allows you to quickly scaffold Azure DevOps repositories using Cookiecutter templates. This streamlines project initialization and ensures consistent repository structure across your organization.

Prerequisites​

  1. Complete the onboarding process.
  2. Access to Azure DevOps with permissions to create repositories and pipelines.

Set up data model​

If you haven't installed the Azure DevOps integration, you'll need to create a blueprint for Azure DevOps repositories.
However, we highly recommend you install the Azure DevOps integration to have this automatically set up for you.

Create the Azure DevOps repository blueprint

  1. Go to your Builder page.

  2. Click on + Blueprint.

  3. Click on the {...} button in the top right corner, and choose "Edit JSON".

  4. Add this JSON schema:

    Azure DevOps Repository Blueprint (Click to expand)
    {
      "identifier": "azureDevopsRepository",
      "title": "Azure DevOps Repository",
      "icon": "Azure",
      "schema": {
        "properties": {
          "url": {
            "title": "URL",
            "type": "string",
            "format": "url",
            "description": "The URL of the Azure DevOps repository"
          },
          "readme": {
            "title": "README",
            "type": "string",
            "description": "The content of the repository's README file"
          },
          "defaultBranch": {
            "title": "Default Branch",
            "type": "string",
            "description": "The default branch of the repository"
          }
        },
        "required": []
      },
      "mirrorProperties": {},
      "calculationProperties": {},
      "relations": {}
    }

  5. Click "Save" to create the blueprint.

Implementation​

Set up Azure DevOps environment​

  1. Create an Azure DevOps Repository called python_scaffolder in your Azure DevOps Organization/Project:

  2. Configure a service connection to Azure DevOps:

    Service connection configuration

    Use port_trigger for both WebHook Name and Service connection name when configuring your Service Connection

Create a self-service action​

  1. Head to the self-service page in Port.

  2. Click on + New Action.

  3. Click on the {...} button in the top right corner, and choose "Edit JSON".

  4. Copy and paste the following JSON configuration:

    Scaffolding new repository (Click to expand)
    {
      "identifier": "azure_scaffolder",
      "title": "Azure Scaffolder",
      "icon": "Azure",
      "trigger": {
        "type": "self-service",
        "operation": "CREATE",
        "userInputs": {
          "properties": {
            "service_name": {
              "icon": "DefaultProperty",
              "title": "Service Name",
              "type": "string",
              "description": "Name of the service to scaffold"
            },
            "azure_organization": {
              "icon": "DefaultProperty",
              "title": "Azure Organization",
              "type": "string",
              "description": "Your Azure DevOps organization name"
            },
            "azure_project": {
              "icon": "DefaultProperty",
              "title": "Azure Project",
              "type": "string",
              "description": "Your Azure DevOps project name"
            },
            "description": {
              "icon": "DefaultProperty",
              "title": "Description",
              "type": "string",
              "description": "Service description"
            }
          },
          "required": [
            "service_name"
          ],
          "order": [
            "service_name",
            "azure_organization",
            "azure_project",
            "description"
          ]
        },
        "blueprintIdentifier": "azureDevopsRepository"
      },
      "invocationMethod": {
        "type": "AZURE_DEVOPS",
        "webhook": "port_trigger",
        "org": "<AZURE_DEVOPS_ORGANIZATION_NAME>",
        "payload": {
          "properties": {
            "service_name": "{{.inputs.\"service_name\"}}",
            "azure_organization": "{{.inputs.\"azure_organization\"}}",
            "azure_project": "{{.inputs.\"azure_project\"}}",
            "description": "{{.inputs.\"description\"}}"
          },
          "port_context": {
            "entity": "{{.entity}}",
            "blueprint": "{{.action.blueprint}}",
            "runId": "{{.run.id}}",
            "trigger": "{{ .trigger }}"
          }
        }
      },
      "requiredApproval": false
    }
    Replace the organization name

    Make sure to replace <AZURE_DEVOPS_ORGANIZATION_NAME> with your actual Azure DevOps organization name.

  5. Click Save to create the action.

Create an Azure DevOps pipeline​

  1. In your python_scaffolder repository, create a file called azure-pipelines.yml in the root with the following content:

    Azure DevOps Pipeline YAML (Click to expand)
    trigger: none

    pool:
      vmImage: "ubuntu-latest"

    variables:
      RUN_ID: "${{ parameters.port_trigger.port_context.runId }}"
      BLUEPRINT_ID: "${{ parameters.port_trigger.port_context.blueprint }}"
      SERVICE_NAME: "${{ parameters.port_trigger.properties.service_name }}"
      DESCRIPTION: "${{ parameters.port_trigger.properties.description }}"
      AZURE_ORGANIZATION: "${{ parameters.port_trigger.properties.azure_organization }}"
      AZURE_PROJECT: "${{ parameters.port_trigger.properties.azure_project }}"

    resources:
      webhooks:
        - webhook: port_trigger
          connection: port_trigger

    stages:
      - stage: fetch_port_access_token
        jobs:
          - job: fetch_port_access_token
            steps:
              - script: |
                  sudo apt-get update
                  sudo apt-get install -y jq
              - script: |
                  accessToken=$(curl -X POST \
                        -H 'Content-Type: application/json' \
                        -d '{"clientId": "$(PORT_CLIENT_ID)", "clientSecret": "$(PORT_CLIENT_SECRET)"}' \
                        -s 'https://api.getport.io/v1/auth/access_token' | jq -r '.accessToken')
                  echo "##vso[task.setvariable variable=accessToken;isOutput=true]$accessToken"
                displayName: Fetch Access Token and Run ID
                name: getToken

      - stage: scaffold
        dependsOn:
          - fetch_port_access_token
        jobs:
          - job: scaffold
            variables:
              COOKIECUTTER_TEMPLATE_URL: "https://github.com/brettcannon/python-azure-web-app-cookiecutter"
            steps:
              - script: |
                  sudo apt-get update
                  sudo apt-get install -y jq
                  sudo pip install cookiecutter -q
              - script: |
                  # Create the repository
                  PROJECT_ID=$(curl -X GET "https://dev.azure.com/${{ variables.AZURE_ORGANIZATION }}/_apis/projects/${{ variables.AZURE_PROJECT }}?api-version=7.0" \
                  -H "Authorization: Basic $(PERSONAL_ACCESS_TOKEN)" \
                  -H "Content-Type: application/json" \
                  -H "Content-Length: 0" | jq .id)

                  if [[ -z "$PROJECT_ID" ]]; then
                    echo "Failed to fetch Azure Devops Project ID."
                    exit 1
                  fi

                  PAYLOAD='{"name":"${{ variables.SERVICE_NAME }}","project":{"id":'$PROJECT_ID'}}'

                  CREATE_REPO_RESPONSE=$(curl -X POST "https://dev.azure.com/${{ variables.AZURE_ORGANIZATION }}/_apis/git/repositories?api-version=7.0" \
                  -H "Authorization: Basic $(PERSONAL_ACCESS_TOKEN)" \
                  -H "Content-Type: application/json" \
                  -d $PAYLOAD)

                  PROJECT_URL=$(echo $CREATE_REPO_RESPONSE | jq -r .webUrl)

                  if [[ -z "$PROJECT_URL" ]]; then
                    echo "Failed to create Azure Devops repository."
                    exit 1
                  fi

                  echo "##vso[task.setvariable variable=PROJECT_URL;isOutput=true]$PROJECT_URL"

                  cat <<EOF > cookiecutter.yaml
                  default_context:
                    site_name: "${{ variables.SERVICE_NAME }}"
                    python_version: "3.6.0"
                  EOF
                  cookiecutter $COOKIECUTTER_TEMPLATE_URL --no-input --config-file cookiecutter.yaml --output-dir scaffold_out

                  echo "Initializing new repository..."
                  git config --global user.email "scaffolder@email.com"
                  git config --global user.name "Mighty Scaffolder"
                  git config --global init.defaultBranch "main"

                  cd "scaffold_out/${{ variables.SERVICE_NAME }}"
                  git init
                  git add .
                  git commit -m "Initial commit"
                  decoded_pat=$(echo $(PERSONAL_ACCESS_TOKEN) | base64 -d)
                  git remote add origin https://$decoded_pat@dev.azure.com/${{ variables.AZURE_ORGANIZATION }}/${{ variables.AZURE_PROJECT }}/_git/${{ variables.SERVICE_NAME }}
                  git push -u origin --all
                name: scaffold

      - stage: upsert_entity
        dependsOn:
          - fetch_port_access_token
          - scaffold
        jobs:
          - job: upsert_entity
            variables:
              accessToken: $[ stageDependencies.fetch_port_access_token.fetch_port_access_token.outputs['getToken.accessToken'] ]
              PROJECT_URL: $[ stageDependencies.scaffold.scaffold.outputs['scaffold.PROJECT_URL'] ]
            steps:
              - script: |
                  sudo apt-get update
                  sudo apt-get install -y jq
              - script: |
                  curl -X POST \
                    -H 'Content-Type: application/json' \
                    -H 'Authorization: Bearer $(accessToken)' \
                    -d '{
                        "identifier": "${{ variables.SERVICE_NAME }}",
                        "title": "${{ variables.SERVICE_NAME }}",
                        "properties": {"description":"${{ variables.DESCRIPTION }}","url":"$(PROJECT_URL)" },
                        "relations": {}
                      }' \
                    "https://api.getport.io/v1/blueprints/${{ variables.BLUEPRINT_ID }}/entities?upsert=true&run_id=${{ variables.RUN_ID }}&create_missing_related_entities=true"

      - stage: update_run_status
        dependsOn:
          - upsert_entity
          - fetch_port_access_token
          - scaffold
        jobs:
          - job: update_run_status
            variables:
              accessToken: $[ stageDependencies.fetch_port_access_token.fetch_port_access_token.outputs['getToken.accessToken'] ]
              PROJECT_URL: $[ stageDependencies.scaffold.scaffold.outputs['scaffold.PROJECT_URL'] ]
            steps:
              - script: |
                  sudo apt-get update
                  sudo apt-get install -y jq
              - script: |
                  curl -X PATCH \
                    -H 'Content-Type: application/json' \
                    -H 'Authorization: Bearer $(accessToken)' \
                    -d '{"status":"SUCCESS", "message": {"run_status": "Scaffold ${{ variables.SERVICE_NAME }} finished successfully!\\n Project URL: $(PROJECT_URL)" }}' \
                    "https://api.getport.io/v1/actions/runs/${{ variables.RUN_ID }}"

      - stage: update_run_status_failed
        dependsOn:
          - upsert_entity
          - fetch_port_access_token
          - scaffold
        condition: failed()
        jobs:
          - job: update_run_status_failed
            variables:
              accessToken: $[ stageDependencies.fetch_port_access_token.fetch_port_access_token.outputs['getToken.accessToken'] ]
            steps:
              - script: |
                  curl -X PATCH \
                    -H 'Content-Type: application/json' \
                    -H 'Authorization: Bearer $(accessToken)' \
                    -d '{"status":"FAILURE", "message": {"run_status": "Scaffold ${{ variables.SERVICE_NAME }} failed" }}' \
                    "https://api.getport.io/v1/actions/runs/${{ variables.RUN_ID }}"
    Customize the template

    You can create your own Cookiecutter templates by following the official guide. Simply update the COOKIECUTTER_TEMPLATE_URL variable in the pipeline YAML to use your own template.

  2. Configure the pipeline in Azure DevOps:

    • Go to Pipelines → Create Pipeline → Azure Repos Git and choose python_scaffolder.
    • Click Save (in the "Run" dropdown menu).

  3. Create the following secret variables in your pipeline:

    • PERSONAL_ACCESS_TOKEN - A base64-encoded Azure DevOps PAT with Code (Full) and Release (Read, write & execute) permissions.
      To encode your Personal Access Token:

      MY_PAT=YourPAT
      B64_PAT=$(printf ":%s" "$MY_PAT" | base64)
      echo $B64_PAT

    • PORT_CLIENT_ID - Port Client ID learn more.

    • PORT_CLIENT_SECRET - Port Client Secret learn more.

Let's test it!​

  1. Head to the self-service page of your portal.
  2. Click on the Azure Scaffolder action.
  3. Fill in the required details:
    • Service Name (required).
    • Azure Organization (if different from default).
    • Azure Project (if different from default).
    • Description.
  4. Click on Execute.
  5. Wait for the Azure DevOps pipeline to create your new repository with the Cookiecutter template.
